Digital electric 3-phases bending machine
Spheroidal cast ironed body on metal steelwork base
3-phases 380V/50 HZ asynchronus, self-braking motor (different voltages upon request), 2 speeds, 2,3/3,1 KW power
Digital electronic unit with display to program and control the required bend angles. Memorises up to 70 bending programs with the possibility to store up to 6 bending angles in sequence in each program
Automatic return to original starting point
Low tension electronic panel (24V)
180° maximum bending angle
Equipped with quick counterformer support position device and 2 interchangable outlet shafts
Dimensions: lenght 810 mm, width 400 mm, height 1100 mm
INTECUT has a strong alloy structure to achieve portable and reliable purpose.
Installation can be finished in 30 minutes.
CNC is with 7” colorful displayer and interfaces, English, Russian, Spanish, Portuguese, French, Danish, Korean and Chinese language.
44 shapes are in CNC library. It is easy for user to choose and set parameters.
Functions are for both flame and plasma cutting.
Program are built in for improving cutting quality, includes speed, pierce time, pulse, motions, etc.
Easy exchanging between flame and plasma cutting model.
USB port for inputting and outputting programs.
Compatible for nesting software, FastCAM, MTC, Turbonest, etc. Drawings from AUTOCAD, TEKLA and SOLIDWORKS are easily used.
High strength, hardness alloy frame works.
Axis cored sliding way are applied on X-beam and Y rails.
High gantry is used for easily feeding plate and unloading workpieces.
Strong and light torch station avoid damage to X-beam.
Fastening parts fix each connection and corner.
Cable chain take and protect cables.
Easy operation of plasma torch holder. Easy exchangement between plasma and oxy-fuel.
Feet are used for adjusting level easily.
7” Displayer, colorful interfaces, English, Russian, Spanish, Portuguese, French, Denish, Korean, Chinese.
44 shapes in controller library.
