Triton with RAM

Currently there is no video available for this product

• Manual band saw machine to cut from 0° to 60° right (manual/gravitational for version +G).
• Available in single and three phase
• Head structure in special aluminium casting alloy.
• Dynamometric blade tensioning.
• Blade cleaning brush integrated in the head protection cover.
• Head handgrip with integrated cycle button.
• Blade guide with combined action of side bearings, carbide plates and top bearing.
• Direct drive: Reduction gear box with inclined grinded case-hardened teeth lubricated with long lasting grease. (Inverter for speed choice 0÷120 m/min for version +VHZ).
• Output shaft of the reduction gear box Ø 40 mm and motor wheel connection with a keyless shaft/hub connection.
• Material clamping vice with manual positioning and fast clamping.
• Ergonomic working table and control panel. Head rotation angle stop at 0°, 45° and 60°.
• Degrees measuring system, graduated scale and rugged in construction locking lever.
• Loading side: Rugged in construction support roller with double positioning.
• Millimetric reference length stop measuring system.
• Cutting length 0÷600 mm. Heavy duty basement.
• Sheet metal construction in different thickness, chips holding sides.
• Front door with key locking.
• Hydraulic cooling pump with 20 l. capacity tank for feeding both blade guides.
• Electrical cabinet with 24VAC, lockable main switch and electric drives.
• Total protection against highest voltage and short circuit current. Protection level IP 55.
